View In:   ArcGIS Online Map Viewer

Parent Layer: Green Infrastructure Considerations

Name: Vacant Land

Display Field: FAC_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This file is a digital geospatial Environmental Systems Research Institute (ESRI) ArcGIS version 10.x File Geodatabase Polygon Feature Class representing land use in the seven northeastern Illinois counties (Cook, DuPage, Kane, Kendall, Lake, McHenry and Will). Land use is identified to nearly 60 categories and was created using county parcel GIS boundaries and Assessor data, along with color orthorectificed aerial photography captured in the spring of YEAR. Land uses were assigned to parcels using a combination of automated and manual techniques, using a variety of reference data sets for land use identification and validation. Parcels were then dissolved on common land uses (to the limits of PLS sections or assessor blocks); polygons were generated for “non-parcel” (water, right-of-way) areas and classified using automated processes, and have been assigned a generic code of 6000 (non-parcel). NOTES: Land use polygons are based on county parcel geometry; special care must be exercised when comparing these data to earlier (2005, 2001, 1990) Inventories, which relied on manual drafting of land use boundaries that would extend to road centerlines. Parcel geometry received from the counties is used “as-is,” meaning there was no attempt to reconcile sliver gaps or overlaps between polygons in a county’s parcel set, nor along county boundaries where parcels may overlap slightly. Values for the landuse and open space management fields are coded domains. See tables domain_LANDUSE and domain_OSMGMT for code descriptions. Full description of land use categories can be found in the accompanying Land Use Classification Scheme PDF document.

Service Item Id: f63fe18ed35e4e6e816445c5d3d69614

Copyright Text: Chicago Metropolitan Agency for Planning staff and interns.

Default Visibility: false

MaxRecordCount: 20000

MaxSelectionCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -9818321.1271
YMin: 5067000.4322
XMax: -9743200.4895
YMax: 5235532.046599999
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [106, 27, 27, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 0]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• FIRST_COUNTY ( type: esriFieldTypeString, alias: COUNTY, editable: true, nullable: true, length: 3, defaultValue: null, modelName: FIRST_COUNTY )
• LANDUSE ( type: esriFieldTypeString, alias: LANDUSE, editable: true, nullable: true, length: 4, defaultValue: null, modelName: LANDUSE )
• LANDUSE2 ( type: esriFieldTypeString, alias: LANDUSE2, editable: true, nullable: true, length: 20, defaultValue: null, modelName: LANDUSE2 )
• OS_MGMT ( type: esriFieldTypeString, alias: OS_MGMT, editable: true, nullable: true, length: 4, defaultValue: null, modelName: OS_MGMT )
• FAC_NAME ( type: esriFieldTypeString, alias: FAC_NAME, editable: true, nullable: true, length: 150, defaultValue: null, modelName: FAC_NAME )
• PLATTED ( type: esriFieldTypeString, alias: PLATTED, editable: true, nullable: true, length: 1, defaultValue: null, modelName: PLATTED )
• MODIFIER ( type: esriFieldTypeString, alias: MODIFIER, editable: true, nullable: true, length: 1, defaultValue: null, modelName: MODIFIER )
• ORIG_FID ( type: esriFieldTypeInteger, alias: ORIG_FID, editable: true, nullable: true, defaultValue: null, modelName: ORIG_FID )
• landuse_desc ( type: esriFieldTypeString, alias: landuse_desc, editable: true, nullable: true, length: 255, defaultValue: null, modelName: landuse_desc )
• LU_long ( type: esriFieldTypeInteger, alias: LU_long, editable: true, nullable: true, defaultValue: null, modelName: LU_long )
• LUcode ( type: esriFieldTypeInteger, alias: LUcode, editable: true, nullable: true, defaultValue: null, modelName: LUcode )
• LUdescription ( type: esriFieldTypeString, alias: LUdescription, editable: true, nullable: true, length: 1073741822, defaultValue: null, modelName: LUdescription )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape_Length, editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength(), required: true )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape_Area, editable: false, nullable: true, defaultValue: null, modelName: Shape.STArea(), required: true )

Templates:

• Name: Vacant Land
  Description:
  Prototype:
  LUdescription: null
  FIRST_COUNTY: null
  LANDUSE: null
  LANDUSE2: null
  OS_MGMT: null
  FAC_NAME: null
  PLATTED: null
  MODIFIER: null
  ORIG_FID: null
  landuse_desc: null
  LU_long: null
  LUcode: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:

Supported Operations:   Query   Query Analytic   Append   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
